Electric three-way internal thread ball valve is a new type of electric three-way ball valve developed by Jingou Company based on comprehensive domestic and foreign advanced technology. Standard ball cores have L-shaped and three-way double-port holes, which can change the relative angle between the ball core and the pipe, and can achieve different combined control of the three pipe fluids; T-shaped channels can play a role of proportion, suitable for liquid, gas, steam And other media ratio adjustment and control. Electric three-way internally threaded ball valve adopts HR and HQ type angular travel electric actuators. It is powered by AC220V, AC380V or DC24V power supply voltage, and accepts (4-20mA, or 1-5VDC) current signals or The voltage signal can control the operation and realize the proportional adjustment or two-position switching control of the process medium.
Electric three-way internal thread ball valve Product features
(1) Electric three-way internally threaded ball valve has two-seat and four-seat seal structure, and the spool hole has two types of structure: L-shaped and T-shape. The valve core rotation angle is controlled to change the connection state between the spool hole and the pipe port. Realize different combination control of the three branch pipes. The three-way ball valve has a large flow capacity and can control gas, liquid, and steam. It is more suitable for controlling high-viscosity, fiber-like granular fluids. It is also suitable for occasions with stricter sealing requirements.
(2) Two-seat sealed three-way ball valve has compact structure, beautiful appearance and good sealing performance, and it can switch the medium flow direction in the pipeline. It is also possible to connect or close two channels that are perpendicular to each other.
(3) The four-seat sealed three-way ball valve has a beautiful shape, compact and reasonable structure. It can not only switch the flow direction of the medium, but also allow the three channels to communicate with each other. At the same time, any one channel can be closed to connect the other two channels. Flexible control piping is the confluence or divergence of media.
(4) T-shaped spool hole can make three orthogonal pipelines communicate or switch with each other to play the role of diverting or converging; L-shaped channel connects two orthogonal pipelines. Cut another channel to change the flow direction of the medium.
Professional manufacturing and professional services, KUNAG creates more value for you
Continuously improving the quality of services and keeping improving, "sincere service" is the eternal theme of KUNAG. Kunag strictly complies with the requirements of ISO9001-2000 quality system certification, strictly controls the quality and responsibilities to the people to ensure the healthy operation of production, sales and service. To strengthen communication with customers and to provide our customers with quality products and perfect service, we hereby make the following commitments:
Product Standards
Products are designed, manufactured, and inspected strictly in accordance with China\'s GB, HG standards, and US API standards. The hardness of the sealing surface meets the national requirements and the width exceeds the national standard.
pre-sale service
Product introduction, technical communication, non-standard product design, troubleshooting.
Sale service
Trustworthy contracts, guarantee timely delivery, and keep in touch with customers at any time.
For special or complex products, our factory arranges technicians to train and guide users on product use, troubleshooting, tuning and maintenance.
After sales service
The warranty period of Weitong products is 12 months from the factory, and the "three guarantees" service (return, replacement, repair) is implemented.
During the use of our products, our factory regularly organizes technical and inspection personnel to visit and solicit user feedback on product quality, use conditions, and improvement opinions in order to further improve product quality.
Quickly respond to customer complaints about product quality problems, and after-sales service personnel rushed to the scene within 24-36 hours (48 hours outside the province).
For after-sales service, users are required to fill in the quality feedback form after the service and make appraisal opinions, while improving Guardian\'s service quality.
Order process
Landline: 021-59718851 (AM-8: 30 to PM-17: 30)
Mobile phone: 18918462396 (WeChat same number 24-hour service)
QQ: 2030185432
Email: kunage@126.com
Receive customer purchase list, provide customers with valve model selection and quotation (price list).
Specific agreement: delivery time, special requirements, etc.
download Google:
Customers have special requirements for products, and must provide the following instructions in the order contract:
(1) Structure length;
(2) Connection form;
(3) Nominal diameter, full diameter, reduced diameter, pipe size;
(4) Operating medium, temperature and pressure range;
(5) Experiment, inspection standards and other requirements;
(6) Various driving devices can be configured in this field according to the special requirements of customers;
If the determined valve type and model are provided by the customer, the customer should correctly explain the meaning and requirements of its model, and sign the contract under the conditions that the supply and demand sides understand and agree.
