SMS-TORK Turkey S1073 (TORK-GT) ECONOMIC GENERAL PURPOSE

  • SMS-TORK product selection Product quotation Technical support After-sales service
  • SMS-TORK is a Turkish company producing industrial control valves and measuring control equipment
  • SMS-TORK is a Turkish company that manufactures industrial control valves and measurement control equipment
  • Product description: Turkey Sms-TorkSms-Tork Solenoid Valve, Sms-Tork Proportional Valve, Sms-Tork Ball Valve, Sms-Tork Butterfly Valve, Sms-Tork Gate Valve, Sms-Tork Dust Removal Valve, Sms-Tork Limit Switch, Sms-Tork Li
  • INQUIRY

GENERAL DETAILS

Application : Air, water, gas
Size : 1/8", 1/2" BSP (on request NPT) 3/8", 1/2" (Pilot Opareted)
Pressure : 0 bar … 16 bar (orifice), 0,5 … 16 bar
Tube and international part : Brass, Stainless Steel
Body : Brass
Seal : NBR, on request VITON
Temperature : .-10°C…80 °C
Position : Normally Closed
Coil Voltage : 230V, 110V , 48V, 24V , 12V  AC ; 110V , 48V , 24V , 12 V DC
Protection Class : IP65 and Exproof models

SPECIFICATION

Valve Type / Order No Connection Size Orifice Size (mm) Pressure (bar) KV  lt/ min Fluid Temperature Seal Weight (kg)
Min Max Min Max
S1073.00.018 1/8" 1,8 0 16 1,6 -10 80 NBR 0,31
S1073.00.025 1/8" 2,5 0 12 3,2 -10 80 NBR 0,31
S1073.00.030 1/8" 3 0 10 4,6 -10 80 NBR 0,31
S1073.00.040 1/8" 4 0 9 6,4 -10 80 NBR 0,31
S1073.00.045 1/8" 4,5 0 8 7,5 -10 80 NBR 0,31
S1073.01.018 1/4" 1,8 0 16 1,6 -10 80 NBR 0,3
S1073.01.025 1/4" 2,5 0 12 3,2 -10 80 NBR 0,3
S1073.01.030 1/4" 3 0 10 4,6 -10 80 NBR 0,3
S1073.01.040 1/4" 4 0 9 6,4 -10 80 NBR 0,3
S1073.01.045 1/4" 4,5 0 8 7,5 -10 80 NBR 0,3
S1073.02.030 3/8" 3 0 10 4,6 -10 80 NBR 0,4
S1073.02.040 3/8" 4 0 9 6,4 -10 80 NBR 0,4
S1073.02.050 3/8" 5 0 7 9,2 -10 80 NBR 0,4
S1073.03.030 1/2" 2 0 10 4,6 -10 80 NBR 0,38
S1073.03.040 1/2" 3 0 9 6,4 -10 80 NBR 0,38
S1073.03.050 1/2" 5 0 7 9,2 -10 80 NBR 0,38
