GENERAL DETAILS

Application : Air, water, gas
Size : 3/8" … 1" BSP (on request NPT)
Pressure : 0,5 bar … 40 bar
Tube and internal part : Stainless Steel
Body : Brass
Seal : PTFE+ VITON
Temperature : .-10°C…80 °C
Position : Normally Open
Coil Voltage : 230V, 110V , 48V, 24V , 12V  AC ; 110V , 48V , 24V , 12 V DC
Protection Class : IP65 ve Exproof models

SPECIFICATION

Types Sizes Orifice
mm
Pressure  (bar) KV  lt/ min Temperatureı  °C Seal / Oring Weight  kg
Min Max Min Max
S1071.02 3/8" 12,5 0,5 40 48 -10 80 NBR 0,71
S1071.03 1/2" 12,5 0,5 40 65 -10 80 NBR 0,74
S1071.04 3/4" 12,5 0,5 40 72 -10 80 NBR 0,82
S1071.05 1" 12,5 0,5 40 76 -10 80 NBR 0,99
