Technical overview
Size range ¼"-8" (DN8-DN200)
Series Range 28 Series - ANSI B16.34 class 2500 (wall thickness), size ¼”-8”(DN8-DN200)
Series 27 - ANSI B16.34 class 2500 (wall thickness), size ¼”-2”(DN8-DN50) ANSI B16.34 class 1500 (wall thickness), size 2½”-8”(DN65-DN200)
Series 24 - Class 2500, size ¼”-1½”(DN8-DN40)
Series 95 - Trunnion Class 1500 (up to 12”)
Series 96 - Trunnion Class 2500 (up to 8”)
Temperature range -60 °C to +260 °C (-76 °F to +500 °F)
Material Stainless Steel 316/316L, Carbon Steel ASTM A350 LF2, C.St A105 and more.
Connection method Threaded, welded, flanged
Compliance Standards
Factory Certification ISO 9001-2015 Quality Management System
ANSI B16.34, API 6D / ISO 14313, ISO 17292 Valve Design
ANSI B1.20.1 NPT - National Pipe Taper Thread
DIN 3852 BSPP - British Standard Paralell Pipe
NACE MR-0175, ISO 15156-1/2/3 Grade for S-containing environments in H2 oil and gas production
EN 12266-1, API 598 Testing of Metallic Valves - Pressure Testing, Test Procedures and Acceptance Criteria. /td>
API 607, ISO 10497 Valve Testing - Fire Type Testing Requirements
(Hebrew) הסמכות ISO 15848-1 ndustrial valves - measurement, test and qualification procedures for fugitive emissions
Certification PED 2014/68/EU Module H Pressure Equipment Directive
ATEX 2014/34/EU Equipment and protective systems for use in potentially explosive atmospheres (optional for actuators only) ((optional for actuators only))
IEC 61508-2 SIL 2/3 Safety Integrity Level - Functional Safety of Electrical/Electronic/Programmable Electronic Safety-Related Systems ((Optional for Execution Units only))
Document EN 10204 2.2 / 3.1 / 3.2 Metallic materials - Types of inspection documents
Professional manufacturing and professional services, KUNAG creates more value for you
Continuously improving the quality of services and keeping improving, "sincere service" is the eternal theme of KUNAG. Kunag strictly complies with the requirements of ISO9001-2000 quality system certification, strictly controls the quality and responsibilities to the people to ensure the healthy operation of production, sales and service. To strengthen communication with customers and to provide our customers with quality products and perfect service, we hereby make the following commitments:
Product Standards
Products are designed, manufactured, and inspected strictly in accordance with China\'s GB, HG standards, and US API standards. The hardness of the sealing surface meets the national requirements and the width exceeds the national standard.
pre-sale service
Product introduction, technical communication, non-standard product design, troubleshooting.
Sale service
Trustworthy contracts, guarantee timely delivery, and keep in touch with customers at any time.
For special or complex products, our factory arranges technicians to train and guide users on product use, troubleshooting, tuning and maintenance.
After sales service
The warranty period of Weitong products is 12 months from the factory, and the "three guarantees" service (return, replacement, repair) is implemented.
During the use of our products, our factory regularly organizes technical and inspection personnel to visit and solicit user feedback on product quality, use conditions, and improvement opinions in order to further improve product quality.
Quickly respond to customer complaints about product quality problems, and after-sales service personnel rushed to the scene within 24-36 hours (48 hours outside the province).
For after-sales service, users are required to fill in the quality feedback form after the service and make appraisal opinions, while improving Guardian\'s service quality.
Order process
Landline: 021-59718851 (AM-8: 30 to PM-17: 30)
Mobile phone: 18918462396 (WeChat same number 24-hour service)
QQ: 2030185432
Email: kunage@126.com
Receive customer purchase list, provide customers with valve model selection and quotation (price list).
Specific agreement: delivery time, special requirements, etc.
download Google:
Customers have special requirements for products, and must provide the following instructions in the order contract:
(1) Structure length;
(2) Connection form;
(3) Nominal diameter, full diameter, reduced diameter, pipe size;
(4) Operating medium, temperature and pressure range;
(5) Experiment, inspection standards and other requirements;
(6) Various driving devices can be configured in this field according to the special requirements of customers;
If the determined valve type and model are provided by the customer, the customer should correctly explain the meaning and requirements of its model, and sign the contract under the conditions that the supply and demand sides understand and agree.
Contact: Peng gong
Q Q: 2030185432
Mobile: 18918462396(WeChat same number - 24 hours service)
Landline: 021-59718851
E-mail :kunage@126.com
