TFP-GI series gas turbine flow
meter
product manual:
PPS body, 0-5VDC output, pulse output
Series TFP-GI Gas Turbine Flow Meters are suitable for a wide variety of industrial, commercial, and laboratory flow applications. These
meters utilize a turbine wheel and electro-optical detection to convert flow rates into a linear 0 to 5 VDC output signal for recording and data logging. A 3-1 / 2 digit LCD informs the user of the actual flow rate. A power adapter or mating cable assembly is required for operation.
Specifications:
Service: Clean dry gases compatible with wetted materials.
Wetted Materials: PPS, acetal, sapphire, glass, epoxy, and fluoroelastomer.
Accuracy: ± 3% of full scale.
Linearity: ± 3% of full scale.
Repeatability: ± 0.5% of full scale.
Temperature Limits: 41 to 131 ° F (5 to 55 ° C); Storage: 32 to 158 ° F (0 to 70 ° C); Sensitivity: ± 0.2% of full scale per ° C.
Pressure Limits: 40 psig (2.8 bar).
Process Connection: Compression fitting, see Catalog page.
Power Requirements: 11.5 to 15 VDC.
Power Consumption: 35 mA @ 12 VDC.
Output Signal: 0 to 5 VDC: Minimum 2.5 kΩ load.
Electrical Connections: Four-pin power and signal connector. A power adapter or mating cable required for operation. See Accessories page.
Display: LCD, 0.39 "(10 mm) digits (only in LPM).
Enclosure Rating: IP10 (NEMA 1).
Weight: 0.23 lb (101 g).
Agency Approvals: CE.
