Product Name: Imported Wafer Type Butterfly Valve Product Model: Buhrer Series
Drive method: manual, turbine, electric, pneumatic Connection: wafer, flange
Structural form: Wafer type Seal structure: Optional rubber, PTFE, RPP, hard seal, etc.
Pressure range: 1.6MPa-6.4MPa Nominal diameter: DN50-2000
Common materials: ductile iron, carbon steel, stainless steel, etc.
Product introduction
The imported wafer type butterfly valve produced by Breer can be driven manually, turbine, electric, pneumatic, and the connection method can be used as the clamp, flange, the structure can be used as the wafer type, and the sealing structure can be used as the rubber, PTFE, RPP, hard seal, etc., pressure range PN1.6MPa-6.4MPa, nominal diameter is DN50-2000mm, the material can choose nodular cast iron, carbon steel, stainless steel, etc. Because the valve is used in a very wide range, the same valve has different combinations in different situations and working conditions.
Product Details
Standard specifications of imported wafer type butterfly valve:
Size: DN50 ~ 2000mm
Applicable temperature: -50 ~ 530 ℃
Maximum pressure: ANSI 150, 300LB
Body material: cast iron, carbon steel, stainless steel, aluminum bronze, etc.
Valve plate material: aluminum bronze, stainless steel
Stem material: stainless steel
Seat material: stainless steel, high polymer, synthetic rubber, polytetrafluoroethylene
Features and advantages:
l Good regulation performance
l Double eccentric structure
l Two-way seal
l Fire safety
l Connection method: Wafer, ear
Application:
Suitable for petrochemical, natural gas, oil refining, power plants, metallurgy, chemical industry, papermaking, pharmaceuticals.
Applicable medium: oil, gas, water, steam, chemicals, powder, various hydrocarbons.
