PVC full diameter ball valve ITEM 612/614

Fluid range: various corrosive liquids in the food industry, chemical preparations, etc.

Mounting dimensions: Threaded connection: DIN/ISO 228/1; adhesive connection: ISO 727 UNI 7442/75

Caliber: DN10~DN100, PN10~PN16

Two links, DN10~DN100, PN10~PN16
Working temperature: 0 ° C to +60 ° C
Corrosion resistant application
Note:
Single-acting valves are installed in the normally closed position when they are shipped from the factory. If other positions are required, please specify.
Ontology form
ITEM 612
ITEM 614
Nominal diameter
3/8”~2” (DN10~DN50)
3/8”~2” (DN10~DN50)
Nominal pressure
PN10-PN16
PN10-PN16
Operating temperature
0°C to +60°C
Connection method
Thread (UNI/ISO 228/1)
Adhesive connection (ISO 727 UNI 7442/75)
Body material
PVC
Core material
PVC
Sealing material
Ethylene propylene rubber EPDM, polytetrafluoroethylene PTFE
Executive agency
Standard DA series: double acting fork type pneumatic actuator
Standard SR Series: Single Action Type Fork Actuator
Fluid range
Various corrosive liquids such as food industry and chemical preparations
