GEM-X | General purpose 3W
Ports size: 1/4 ” – 3/4″ BSP, NPT
Orifice size: 8.0 – 19.0 mm
Body material: Brass

Function 3 Way General purpose
Ports size 1/4", 3/8", 1/2", 3/4" BSP & NPT
Pressure range See table
Kv (l/min) See table
Temperature range Fluid : -10ºC to 80ºC (no freezing)
Ambient : -10ºC to 50ºC
Materials in contact
with media
Main Valve:
Brass
Solenoid Operator:
Stainless Steel AISI 300 & 400 series
Seals:
NBR, EPDM
Media Air, water, oil
Coil voltage • Voltage and power consumption - see table
• All Baccara coil voltages are ± 10% of nominal
Standard protection class IP65 with connector
* Option : IP68 (please refer to GEM-BP Coil)
