Code No. Type Interface Filter Precision (Condensate Discharge)
MX2-3/8-F00 filter G3/8 25 semi-automatic drainage
MX2-1/2-F00 filter G1/2 25 semi-automatic drainage
MX2-3/4-F00 filter G3/4 25 semi-automatic drainage
MX3-3/4-F00 filter G3/4 25 semi-automatic drainage
MX3-1-F00 filter G1 25 semi-automatic drainage
MX2-3/8-F03 filter G3/8 25 automatic drainage
MX2-1/2-F03 Filter G1/2 25 Automatic Drainage
MX2-3/4-F03 filter G3/4 25 automatic drainage
MX3-3/4-F03 filter G3/4 25 automatic drainage
MX3-1-F03 Filter G1 25 Automatic Drainage
MX2-3/8-F05 Filter G3/8 25 Protected Pressure-reducing Drainage
MX2-1/2-F05 Filter G1/2 25 Protected Pressure-reducing Drainage
MX2-3/4-F05 Filter G3/4 25 Protected Pressure-reducing Drainage
MX3-3/4-F08 Filter G3/4 25 No Condensate Discharge
MX3-1-F08 Filter G1 25 No Condensate Discharge
MX2-3/8-F08 Filter G3/8 25 No Condensate Discharge
MX2-1/2-F08 Filter G1/2 25 No Condensate Discharge
MX2-3/4-F08 Filter G3/4 25 No Condensate Discharge
MX3-3/4-F10 filter G3/4 5 semi-automatic drainage
MX3-1-F10 filter G1 5 semi-automatic drainage
MX2-3/8-F10 filter G3/8 5 semi-automatic drainage
MX2-1/2-F10 filter G1/2 5 semi-automatic drainage
MX2-3/4-F10 filter G3/4 5 semi-automatic drainage
MX3-3/4-F13 filter G3/4 5 automatic drainage
MX3-1-F13 filter G1 5 automatic drainage
MX2-3/8-F13 filter G3/8 5 automatic drainage
MX2-1/2-F13 filter G1/2 5 automatic drainage
MX2-3/4-F13 filter G3/4 5 automatic drainage
MX3-3/4-F18 Filter G3/4 5 No Condensate Discharge
MX3-1-F18 Filter G1 5 No Condensate Discharge
MX2-3/8-F15 Filter G3/8 5 Protected Pressure-reducing Drainage
MX2-1/2-F15 Filter G1/2 5 Protected Pressure-reducing Drainage
MX2-3/4-F15 Filter G3/4 5 Protected Pressure-reducing Drainage
MX2-3/8-F18 Filter G3/8 5 No Condensate Discharge
MX2-1/2-F18 Filter G1/2 5 No Condensate Discharge
MX2-3/4-F18 Filter G3/4 5 No Condensate Discharge

Code No. Type Interface Filter Precision (Condensate Discharge)
MX2-3/8-FC00 coalescent filter G3/8 0,01 semi-automatic drainage
MX2-1/2-FC00 coalescent filter G1/2 0,01 semi-automatic drainage
MX2-3/4-FC00 coalescent filter G3/4 0,01 semi-automatic drainage
MX3-3/4-FC00 coalescent filter G3/4 0,01 semi-automatic drainage
MX3-1-FC00 Coalescent Filter G1 0,01 Semi-automatic Drainage
MX2-3/8-FC03 coalescent filter G3/8 0,01 automatic drainage
MX2-1/2-FC03 coalescent filter G1/2 0,01 automatic drainage
MX2-3/4-FC03 coalescent filter G3/4 0,01 automatic drainage
MX3-3/4-FC10 coalescent filter G3/4 1 semi-automatic drainage
MX3-1-FC10 coalescent filter G1 1 semi-automatic drainage
MX2-3/8-FC05 Coalescent Filter G3/8 0,01 Protected Pressure-reducing Drainage
MX2-1/2-FC05 Coalescent Filter G1/2 0,01 Protected Pressure-reducing Drainage
MX2-3/4-FC05 Coalescent Filter G3/4 0,01 Protected Pressure-reducing Drainage
MX3-3/4-FC08 Coalescent Filter G3/4 0,01 No Condensate Discharge
MX3-1-FC08 Coalescent Filter G1 0,01 No Condensate Discharge
MX2-3/8-FC08 Coalescent Filter G3/8 0,01 No Condensate Discharge
MX2-1/2-FC08 Coalescent Filter G1/2 0,01 No Condensate Discharge
MX2-3/4-FC08 Coalescent Filter G3/4 0,01 No Condensate Discharge
MX3-3/4-FC18 Coalescent Filter G3/4 1 No Condensate Discharge
MX3-1-FC18 Coalescent Filter G1 1 No Condensate Discharge
MX2-3/8-FC10 coalescent filter G3/8 1 semi-automatic drainage
MX2-1/2-FC10 coalescent filter G1/2-1 semi-automatic drainage
MX2-3/4-FC10 coalescent filter G3/4 1 semi-automatic drainage
MX3-3/4-FC03 coalescent filter G3/4 0,01 automatic drainage
MX3-1-FC03 coalescent filter G1 0,01 automatic drainage
MX2-3/8-FC13 Coalescent Filter G3/8 1 Automatic Drainage
MX2-1/2-FC13 Coalescent Filter G1/2-1 Automatic Drainage
MX2-3/4-FC13 Coalescent Filter G3/4 1 Automatic Drainage
MX3-3/4-FC13 Coalescent Filter G3/4 1 Automatic Drainage
MX3-1-FC13 Coalescent Filter G1 1 Automatic Drainage
MX2-3/8-FC15 Coalescent Filter G3/8 1 Protected Pressure-reducing Drainage
MX2-1/2-FC15 Coalescent Filter G1/2-1 Protected Pressure-reducing Drainage
MX2-3/4-FC15 Coalescent Filter G3/4 1 Protected Pressure-reducing Drainage
MX2-3/8-FC18 Coalescent Filter G3/8 1 No Condensate Discharge
MX2-1/2-FC18 Coalescent Filter G1/2-1 No Condensate Discharge
MX2-3/4-FC18 Coalescent Filter G3/4 1 No Condensate Discharge

Code number, type, interface
MX2-3/8-FCA Activated Carbon Filter G3/8
MX2-1/2-FCA Activated Carbon Filter G1/2
MX2-3/4-FCA Activated Carbon Filter G3/4
MX3-3/4-FCA Activated Carbon Filter G3/4
MX3-1-FCA Activated Carbon Filter G1

Code Type Interface Working Pressure Function Pressure Gauge
MX2-3/8-R000 Pressure Reducer G3/8 0,5_10 Overflow
MX2-1/2-R000 Pressure Reducer G1/2 0,5_10 Overflow
MX2-3/4-R000 Pressure Reducer G3/4 0,5_10 Overflow
MX3-3/4-R004 Pressure Reducer G3/4 0,5_10 Overflow is
MX3-1-R004 Pressure Reducer G1 0,5_10 Overflow is
MX2-3/8-R004 Pressure Reducer G3/8 0,5_10 Overflow is
MX2-1/2-R004 Pressure Reducer G1/2 0,5_10 Overflow is
MX2-3/4-R004 Pressure Reducer G3/4 0,5_10 Overflow is
MX3-3/4-R014 decompressor G3/4 0,5_10 non-overflow is
MX3-1-R014 decompressor G1 0,5_10 non-overflow is
MX2-3/8-R010 Pressure Reducer G3/8 0,5_10 Non-overflow
MX2-1/2-R010 Pressure Reducer G1/2 0,5_10 Non-overflow
MX2-3/4-R010 Pressure Reducer G3/4 0,5_10 Non-overflow
MX3-3/4-R402 Pressure Reducer G3/4 0_4 Overflow is
MX3-1-R402 decompressor G1 0_4 overflow is
MX2-3/8-R014 Pressure Reducer G3/8 0,5_10 Non-overflow is
MX2-1/2-R014 Pressure Reducer G1/2 0,5_10 Non-overflow is
MX2-3/4-R014 decompressor G3/4 0,5_10 non-overflow is
MX3-3/4-R412 decompressor G3/4 0_4 non-overflow is
MX3-1-R

Order process
Landline: 021-59718851 (AM-8: 30 to PM-17: 30)
Mobile phone: 18918462396 (WeChat same number 24-hour service)

QQ: 2030185432

Email: kunage@126.com
Receive customer purchase list, provide customers with valve model selection and quotation (price list).
Specific agreement: delivery time, special requirements, etc.
download Google:
Customers have special requirements for products, and must provide the following instructions in the order contract:
(1) Structure length;
(2) Connection form;
(3) Nominal diameter, full diameter, reduced diameter, pipe size;
(4) Operating medium, temperature and pressure range;
(5) Experiment, inspection standards and other requirements;
(6) Various driving devices can be configured in this field according to the special requirements of customers;
If the determined valve type and model are provided by the customer, the customer should correctly explain the meaning and requirements of its model, and sign the contract under the conditions that the supply and demand sides understand and agree.
