  • Flange stop valve American Standard German standard Japanese standard national standard forged steel
Flange stop valve American Standard German standard Japanese standard national standard forged steel

Flange stop valve American Standard German standard Japanese standard national standard forged steel

  • Vision: kunag will become one of the leading global fluid control brands
  • Objective: kunag focuses on the field of fluid control and subsystem solutions
  • Fluid control equipment in the field of petrochemical technology and medical equipment
  • Product description: KUNAG is a company specializing in the research and development, production, customization and system integration of components in the field of fluid control. Its products mainly include corrosion-res
  • INQUIRY
Design and manufacturing standards
The design and manufacture shall be in accordance with GB / T 12235 and DIN 3356
The structural length shall be in accordance with GB / T 12221 and DIN 3202
Flange connection dimensions shall be in accordance with JB / T 79 and din 2543
Inspection according to GB / T 26480 and din 3230

Performance specification
Nominal pressure: 1.6,2.5,4.0,6.3mpa
Strength test: 2.4, 3.8, 6.0, 9.5Mpa
Sealing test: 1.8, 2.8, 4.4, 7.0Mpa
Airtight seal test: 06mpa
Valve body materials: WCB (c), CF8 (P), CF3 (PL),
CF8M(R), CF3M(RL)
Applicable media: water, steam, oil, nitric acid and acetic acid
Applicable temperature: - 29 ℃ ~ 425 ℃
