The Liquisys COM223 standard
transmitter can be used in conjunction with the dissolved oxygen measuring
sensors COS41 and COS61. Improve operational safety through continuous rationality testing and process and
sensor testing. Choose from numerous hardware and software modules (such as relays and bus communication) to meet the needs of measurement tasks. It also allows the
transmitter to be upgraded at any time. The simple menu and calibration make the instrument setup and operation convenient and quick.
Advantage
Higher operational safety: continuous process inspection system, customized alarm settings, calibration authenticity check
Reliable dissolved oxygen control: current input is used for flow rate monitoring and feedforward control with
controller shutdown
Simple operation and maintenance: simple one-point calibration in air, oxygen-saturated water or medium, direct manual touch control
Reduce maintenance: trigger automatic cleaning function by alarm or limit switch (using Chemoclean)
Suitable for various applications: multiple extended functions, such as P(ID)
controller, timer, etc., can be flexibly applied to various processes
Application field
Liquisys COM223
transmitter can be matched with Oxymax COS41 and Oxymax COS61 dissolved oxygen
sensors for environmental protection industry measurement, such as:
O2 aeration tank control
O2 drinking water control and monitoring
Surface water monitoring
Process water treatment and monitoring
Optimal control of O2 fish pond growth conditions
Liquisys COM223 uses the following communication protocols and interfaces:
0/4...20 mA
HART
PROFIBUS DP
PROFIBUS PA
Commonly used model: COM223-DX0005
oxygen
Measuring principle Dissolved oxygen
sensor
Application water, sewage, process
Features Four-wire
transmitter with two-line display
Design Dissolved oxygen
transmitter, installed in a panel housing.
Material Panel-mounted shell
Dimensions 96mm x 96mm x 146mm (installation depth)
3.74x3.74x5.61inch (installation depth)
Temperature
sensor display and current output
Connect IP65
Input Single channel type
transmitter
Output 0/4...20 mA, Hart, Profibus.
Other certificates CSA general certification
