Baumer

  • IFFM 12 - Inductive Proximity Switch
IFFM 12 - Inductive Proximity Switch

IFFM 12 - Inductive Proximity Switch

  • Installation Type Shielded
  • Rated sensing distance Sn 4 mm
  • Hysteresis 3 ... 20 % (Sr)
  • Output indicator LED red
  • Product description: Baumer brand products include non-detection, inductive, photoelectric, ultrasonic, capacitive, magnetic sensors, mechanical precision switches, ranging, inductive, laser ranging, optical cutting, edge
  • INQUIRY
Order code output circuit
IFFM 12N17A3/S05L NPN Normally Open (NO)
IFFM 12N37A3/S05L NPN Normally Closed (NC)
IFFM 12P17A3/S05L PNP Normally Open (NO)
IFFM 12P37A3/S05L PNP Normally Closed (NC)

Basic parameters
Installation Type Shielded
Rated sensing distance Sn 4 mm
Hysteresis 3 ... 20 % (Sr)
Output indicator LED red

Electrical parameter
Switching frequency < 2 kHz
Operating voltage range +Vs 10 ... 30 VDC
Current consumption (maximum) (no load) 10 mA
Voltage drop Vd < 2 VDC
Output current < 200 mA
Short circuit protection
Reverse polarity protection

Mechanical parameters
Type right angle
Material (sensing surface) PBT
Housing Material Brass Nickel Plating
Size 12 mm
Shell length 23,5 mm
Connector target='_blank'>Connector Type Connector target='_blank'>Connector M5

Environmental conditions
Operating temperature -25 ... +75 °C

Protection level
