GENERAL DETAILS |
||
| Operation | : | Gas |
| Size | : | 3/8''….1'' BSP (on request NPT ) |
| Pressure | : | 0 bar …..16 bar(^p:0 bar ) |
| Internal Parts | : | Stainless Steel |
| Body | : | Brass |
| Sealing Materials | : | NBR on request EPDM or VITON |
| Temparature | : | :-10°C - + 80°C |
| Position | : | Normally Closed |
| Coil Voltage | : | 230V, 110V , 48V, 24V , 12V AC ; 110V , 48V , 24V , 12 V DC |
| Protection Class | : | :IP67 , II2G Ex mb IIC T4 Gb Exproof , ATEX Certificated |
| Serial Number | Connection Size | Orifice Size | Min | Max | KV lt/hr | Min | Max | Seal/Oring | Weight |
| S7320.02 | 3/8'' | 12,5 mm | 0 | 16 | 38 | -10 | 80 | NBR | 0,91 |
| S7320.03 | 1/2'' | 14,5 mm | 0 | 16 | 62 | -10 | 80 | NBR | 0,94 |
| S7320.04 | 3/4'' | 17 mm | 0 | 16 | 85 | -10 | 80 | NBR | 1,02 |
| S7320.05 | 1'' | 17 mm | 0 | 16 | 100 | -10 | 80 | NBR | 1,2 |
