| Application | : | Gas |
| Size | : | 1/8"…1" BSP (on request NPT) |
| Pressure | : | 0-9 bar (1/4", 1/8") , 1-16 bar ( 3/8"...1") |
| Internal Parts | : | Stainless Steel |
| Body | : | Brass |
| Sealing Materials | : | NBR (on request Viton) |
| Working Temperature | : | -10°C…80 °C |
| Position | : | Normally Closed |
| Coil voltage | : | 230V, 110V , 48V, 24V , 12V AC ; 110V , 48V , 24V , 12 V DC |
| Protection Class | : | IP65 and Exproof |
| Connection Size | Code No | Pressure Bar | Description |
| 1/8" | S 8010.00.040 | 0 - 9 | 2/2 Way, 4 mm orifice |
| 1/4" | S 8010.01.040 | 0 - 9 | 2/2 Way, 4 mm orifice |
| 3/8" | S 8010.02 | 1 - 16 | 2/2 Way, 12.5 mm orifice |
| 1/2" | S 8010.03 | 1 - 16 | 2/2 Way, 14.5 mm orifice |
| 3/4 | S 8010.04 | 1 - 16 | 2/2 Way, 17 mm orifice |
| 1" | S 8010.05 | 1 - 16 | 2/2 Way, 17 mm orifice |
