| Application | : | Liquid, gas, air, water, hot water, steam | ||||||||||||
| Type No | : | PAV 905…DA / PAV 905 SR | ||||||||||||
| On Request | : | Limit switch box, positioner, namur solenoid valve, manuel override | ||||||||||||
| Actuator | : | RA…DA Double Acting Actuators / RA…SR Single Acting Actuators | ||||||||||||
| Air Supply | : | 4-6 bar, Stroke adjustment | ||||||||||||
| Valve Code | : | TORK-KV 905 | ||||||||||||
| Valve Body Material | : | AISI 316 SS , Optional AISI 304 SS | ||||||||||||
| Connection | : | Flanged | ||||||||||||
| Pressure | : | PN 40, PN 25 | ||||||||||||
| Temperature | : | .-40 … 180°C | ||||||||||||
| Size | : | DN 15 ... DN 100 | ||||||||||||
|
TORK-PAV 905 Pneumatic Actuated Stainless Steel Ball Valves, 2/2 Way , Flanged |
| Connection Size | Order Number | Way | Pressure | Temperature | |
| DN15 | TORK-PAV 905.15SR/DA | 2/2 | 0-40 bar | -20..180 C | |
| DN20 | TORK-PAV 905.20SR/DA | 2/2 | 0-40 bar | -20..180 C | |
| DN25 | TORK-PAV 905.25SR/DA | 2/2 | 0-40 bar | -20..180 C | |
| DN32 | TORK-PAV 905.32SR/DA | 2/2 | 0-40 bar | -20..180 C | |
| DN40 | TORK-PAV 905.40SR/DA | 2/2 | 0-40 bar | -20..180 C | |
| DN50 | TORK-PAV 905.50SR/DA | 2/2 | 0-40 bar | -20..180 C | |
| DN65 | TORK-PAV 905.65SR/DA | 2/2 | 0-40 bar | -20..180 C | |
| DN80 | TORK-PAV 905.80SR/DA | 2/2 | 0-40 bar | -20..180 C | |
| DN100 | TORK-PAV 905.100SR/DA | 2/2 | 0-40 bar | -20..180 C | |
