| Application | : | Air, water, gas | |||||||||
| Size | : | 1/8"…….1/4" BSP (on request NPT) | |||||||||
| Pressure | : | 0 bar…16bar (on request 2.5 mm, 2.5 mm orifice) | |||||||||
| Tube and internal part | : | Stainless Steel | |||||||||
| Body | : | Brass | |||||||||
| Seal | : | Viton, on request EPDM or NBR | |||||||||
| Temperature | : | .-10°C…160 °C | |||||||||
| Position | : | Normally Closed | |||||||||
| Coil Voltage | : | 230V, 110V , 48V, 24V , 12V AC ; 110V , 48V , 24V , 12 V DC | |||||||||
| Protection Class | : | IP65 ve Exproof models | |||||||||
| Valve Type / Order No | Connection Size | Orifice Size (mm) | Pressure (bar) | KV lt/ min | Fluid Temperature°C | Seal | Weight (kg) | |||||
| Min | Max | Min | Max | |||||||||
| N.C | N.O | Diversion Systems | ||||||||||
| S1018.00.018 | 1/8" | 1,8 | 0 | 4 | 7 | 16 | 1,5 | -10 | 160 | VITON | 0,44 | |
| S1018.00.025 | 1/8" | 2,5 | 0 | 3 | 4 | 12 | 3 | -10 | 160 | VITON | 0,44 | |
| S1018.00.035 | 1/8" | 3,5 | 0 | 1 | 2 | 10 | 5 | -10 | 160 | VITON | 0,44 | |
| S1018.01.018 | 1/4" | 1,8 | 0 | 4 | 7 | 16 | 1,5 | -10 | 160 | VITON | 0,43 | |
| S1018.01.025 | 1/4" | 2,5 | 0 | 3 | 4 | 12 | 3 | -10 | 160 | VITON | 0,43 | |
| S1018.01.035 | 1/4" | 3,5 | 0 | 1 | 2 | 10 | 5 | -10 | 160 | VITON | 0,43 | |
